Dobot CR30H telescoping palletizing workstation stacking a case onto a shipping pallet with its vacuum gripper, lifting column raised

Product Description

The Dobot CR30H Telescoping Palletizing Workstation is a complete, ready-to-deploy palletizing system, not just a robot arm. Built around the CR30H heavy-payload collaborative robot and a telescoping lifting column, it is configured with the vacuum gripper, lifting base, and palletizing software you need to run end-of-line palletizing — so you deploy a working cell rather than integrate a parts list yourself. For plant and automation managers who want a turnkey cell, this workstation handles a 30 kg total payload and uses its lifting column to reach the upper layers of a full shipping pallet.

It suits manufacturers and 3PLs that are automating case and box palletizing and want one vendor accountable for the whole cell — robot, lift, end effector, and software scoped to work together from day one. Pairing a 30 kg payload with a telescoping lift targets tall, heavy case stacking that lighter, fixed-height cobot cells struggle to build in a single pass.

Key Benefits

  • Deploy a full cell, not a project — the workstation pairs the CR30H robot with a telescoping base and is configured with a vacuum gripper and palletizing software, so you skip much of the integration guesswork and start stacking cases sooner.
  • Build taller pallets with the lift — the telescoping lifting column raises the robot as the stack grows, so a single cell can reach the upper layers of a full shipping pallet without a riser or a second pass.
  • Handle heavy cases all shift — a 30 kg total payload lets the cell palletize dense boxes, cases, and sacks that lighter cobots cannot lift.
  • Cover a wide pallet footprint — 1800 mm of robot reach lets a single arm service a broad stacking area, useful for mixed or multi-pallet layouts.
  • Repeatable return to taught positions — the CR30H's ±0.05 mm repeatability lets the arm hit the same programmed points run after run; final stack alignment also depends on your gripper, cases, and pallet pattern, which we help you dial in.
  • Change SKUs without re-engineering — the palletizing software sets up new pallet patterns and workflows quickly, so short runs and frequent changeovers stay productive.

Ideal Applications

  • End-of-line palletizing of boxes and cases in food, beverage, and consumer-goods plants.
  • Replacing manual stacking of heavy 30 kg loads to cut ergonomic injury risk.
  • Building tall, shipping-ready pallets of heavy cases where a fixed-height cobot cell would otherwise need a riser or a second pass.
  • Low-to-mid-volume lines that need frequent pattern changeovers between SKUs.
  • Facilities adding collaborative automation where a space-saving cell that can work near people, subject to a site risk assessment, matters.

Specifications

Type Lifting palletizing workstation (bundle)
Robot Dobot CR30H, 6-axis collaborative
Total payload 30 kg
Robot reach 1800 mm
Lift Telescoping lifting column (raises the robot for upper pallet layers)
Repeatability ±0.05 mm
Max joint speed J1/J2 150, J3 200, J4–J6 300 deg/s (free motion, not a palletizing cycle rate)
Robot net weight 98.5 kg
Protection (robot body) IP67
Configured with Telescoping base, CR30H robot, vacuum gripper, palletizing software
Country of origin China

Frequently Asked Questions

How much can the Dobot CR30H palletizing workstation lift?

The system handles a 30 kg total payload, enough for dense boxes, cases, and sacks that lighter collaborative robots cannot manage.

What throughput can the cell achieve?

Palletizing cycle rate is set by your case weight and size, pick-and-place distances, lift travel to the top layer, pallet pattern, and gripper cycle time rather than by the robot's free-motion joint speeds, so cells of this type typically run at a modest, few-cases-per-minute pace that shifts with those factors. We model the expected rate for your specific cases and pallet spec during sizing and confirm it on your quote.

How does it reach the top of a full pallet?

The telescoping lifting column raises the CR30H as the stack grows, and the robot's 1800 mm reach covers the pallet footprint, so a single cell can place upper layers without a riser or a second pass. We size the lift to your target pallet height before you buy.

How consistent is case placement?

The CR30H offers ±0.05 mm repeatability, so the arm returns to taught positions reliably. That tight repeatability contributes to consistent, well-aligned placement; overall stack quality also depends on your gripper, cases, and pallet pattern, which we help you dial in.

Is it safe to run alongside workers?

The workstation is built around the CR30H 6-axis collaborative robot, a cobot-class arm intended to work near people. As with any palletizing cell, confirm your specific duty cycle, payload, and layout against a site risk assessment; our team can help you scope this.

How do I program pallet patterns, and what is in the cell?

The cell is configured with palletizing software for fast setup of pallet patterns and workflows, alongside the CR30H robot, telescoping base, and vacuum gripper. Tell us your cases and pallet spec and we will confirm the exact scope of supply on your quote.

Why Buy From Robo Mechanix

We are automation specialists focused on industrial and collaborative robots, so you are talking to people who understand palletizing cells, not a general catalog reseller.

We help you size the system to your cases, pallet heights, and throughput before you buy, so the workstation fits your line.

We support integration from quote through deployment and stay responsive when you have questions after install.

Need the arm on its own or want to compare the family? See the Dobot CR30H heavy-payload collaborative robot or browse all Dobot robots.
