Dobot Nova 5 six-axis collaborative robot arm mounted upright on a workcell, full-body view

Product Description

When an assembly or machine-tending cell needs more reach than a compact cobot offers but not the footprint of a long-reach arm, the Dobot Nova 5 collaborative robot hits the balance. This 6-axis cobot pairs a 5 kg payload with an 850 mm working radius and holds ±0.05 mm repeatability, so a single arm can tend a CNC door, place a sub-assembly, and return to a feeder with the reach to span the cell and the precision to land each move. For engineers and integrators sizing a mid-duty workcell, that balance of reach and precision is where the Nova 5 sits in the Dobot family—the mid model between the lighter, more compact Nova 2 and the longer-reach CR-A series such as the 900 mm CR5A—holding repeatable ±0.05 mm positioning on every cycle.

That mid-tier sizing is deliberate: a 5 kg payload and 850 mm span are enough to fold a multi-step assembly or machine-tending task onto one arm, while the compact body and any-angle mounting let it install at the ceiling, wall, or an inverted angle to fit the layout the cell already has.

Key Benefits

  • Cover a wider workcell with one arm — the 850 mm working radius lets the Nova 5 reach across a machine, a fixture, and an outfeed from a single mount, cutting the station count in multi-step tending jobs.
  • Handle real production parts — the 5 kg payload carries typical grippers, small castings, trays, and assembled modules, so the arm earns its place on assembly and pick-and-place lines rather than demo benches.
  • Keep placements consistent — ±0.05 mm repeatability holds insertions, screw-driving, and dispensing within tolerance cycle after cycle, well matched to the general assembly, tending, and handling tasks the Nova 5 is built for.
  • Mount it where the cell needs it — any-angle installation means ceiling, wall, or inverted mounting to fit tight layouts and free up bench space around existing equipment.
  • Keep transfer moves quick — up to 2 m/s TCP speed speeds the point-to-point transfer and loading moves that link a multi-step cell, so the wider 850 mm reach does not come at the expense of cycle time.
  • Drop into existing control systems — TCP/IP, Modbus TCP, and RS485 plus end-of-arm and controller I/O let integrators wire the Nova 5 to PLCs, grippers, and vision without custom middleware.

Ideal Applications

Machine tending for CNC, injection molding, and press cells where the 850 mm reach spans the door and the staging table.

Assembly, insertion, and screw-driving where consistent ±0.05 mm repeatability keeps each placement within tolerance.

Pick-and-place, kitting, and tray loading of parts up to the 5 kg payload.

Light industrial, service, and lab automation that benefit from any-angle mounting in a compact footprint.

Specifications

Type Collaborative robot (6-axis)
Degrees of freedom 6
Payload 5 kg
Reach (working radius) 850 mm
Repeatability ±0.05 mm
Weight 14 kg
Max TCP speed 2 m/s
Joint ranges J1/J4/J5/J6 ±360°, J2 ±180°, J3 ±160°
Max joint speed 100°/s
Controller input 30–60 V DC
Power consumption 230 W typical, 770 W max
Communication TCP/IP, Modbus TCP, RS485
I/O End-of-arm 2 DI / 2 DO; controller 8 DI / 8 DO (NPN/PNP), 2 AI / 2 AO
Robot cable length 3 m
Ingress protection Robot arm IP54; controller IP20
Noise level 70 dB(A)
Operating temperature 0°C to 50°C
Controller operating humidity ≤95% non-condensing

Frequently Asked Questions

What payload does the Dobot Nova 5 handle?
The Nova 5 is rated for a 5 kg payload, suitable for common grippers, small parts, trays, and light sub-assemblies. When sizing a task, add the end-effector (gripper) weight to the part weight so the combined load stays within the 5 kg rating.

What is the reach of the Nova 5?
It has an 850 mm working radius, giving a single arm enough span to tend a machine and a staging area from one mount. Paired with the 5 kg payload and ±0.05 mm repeatability, that balance of reach and precision is what positions the Nova 5 as the mid model in the Dobot cobot range.

How repeatable is it?
Repeatability is ±0.05 mm, which is sufficient to hold insertions, dispensing, and placements within tolerance across repeated cycles for general assembly and handling work.

How is the Nova 5 programmed?
You program and teach the Nova 5 through Dobot's software environment (commonly DobotStudio Pro), which combines graphical, flow-based programming with hand-guided teaching, so integrators can build and run routines from a workstation at the cell. We confirm the exact current software package and any companion app with you before deployment.

Is the Nova 5 safe to work near people?
Yes—within a properly risk-assessed collaborative cell. As a power-and-force-limiting collaborative robot, the Nova 5 uses built-in collision detection to sense unexpected contact and stop, which is what lets it share workspace with operators under the ISO/TS 15066 guidance for collaborative operation. The safe speed and force limits depend on the end-effector, payload, and application, so each deployment still needs its own risk assessment.

How does it connect to other equipment?
The Nova 5 supports TCP/IP, Modbus TCP, and RS485, plus I/O—2 DI / 2 DO at the end of arm and 8 DI / 8 DO (NPN/PNP) with 2 analog inputs and 2 analog outputs at the controller—for integration with PLCs, grippers, and vision.

Why Buy From Robo Mechanix

We are automation specialists focused on industrial and collaborative robots, not a general catalog reseller.

We help you confirm payload, reach, and application fit before you buy, so the Nova 5 is right-sized for your cell.

Our team supports integration planning, from mounting and I/O to controller communication.

You get responsive service from people who know these platforms and can keep your project moving.

Comparing the family? The Nova 5 sits in the middle: step down to the lighter, more compact Dobot Nova 2 collaborative robot for tighter workspaces, or step up in reach to the 900 mm Dobot CR5A collaborative robot in the CR-A series. You can also browse all Dobot robots.
